Printing mode heat transfer/heat transfer
Resolution 203 dpi (8 dots/mm)
Print speed 4 IPS (102 mm/s)
Print width 4.25 "(108 mm)
Print length Min. 10 mm (0.39 "); Max. 1727 mm (68 ")
Memory 4MB Flash / 8MB SDRAM
Type fixed, reflective (black label), transparent (spacing)
Paper type: continuous paper, pitch paper, black line mark paper or punch paper, the label length can be automatically detected or manually controlled
Paper width: 25.4 mm (1 inch) ~ 118 mm (4.64 inch)
Paper thickness: 0.06 mm (0.003-inch) ~ 0.20mm (0.0008 inch)
Outside diameter: 127 mm (5 ") diameter
Paper roll core: 25.4 mm (1 inch) / 38.1 mm (1.5 inch)
Carbon belt specification material: general waxy type, mixed type, resist scraping resin
Length: 110m (360 feet)
Width: 30 mm to 110 mm (1.18 inches to 4.33 inches)
Maximum size: 40mm (1.57 inches)
Shaft core: 12.7 mm (0.5 inch)
Programming Language EZPL GEPL (Godex Eltron ® Printer Language), GZPL (Godex Zebra ® Printer Language)
Random software volume typesetting software: QLabel IV (supporting EZPL only)
Driver & DLL: supports Windows 2000, XP and Vista
Built-in font fonts: 6, 8, 10, 12, 14, 18, 24, 30, 16X26 and OCR A & B
Bitmap fonts print direction can rotation Angle for 0 °, 90 °, 180 °, 270 °, the font can be single rotation Angle for 0 °, 90 °, 180 °, 270 °
The dot matrix font can be magnified eight times horizontally or vertically
Vector fonts (scalable font), rotation Angle for 0 ° and 90 °, 180 °, 270 °
Download the font bitmap fonts, downloadable print direction can rotation Angle for 0 °, 90 °, 180 °, 270 °. Font rotation Angle for 0 ° and 90 °, 180 °, 270 °, can be horizontal or vertical amplifier 8 times
Asia downloadable fonts, print direction can rotation Angle for 0 °, 90 °, 180 °, 270 °, can be horizontal or vertical amplifier 8 times
Downloadable vector fonts (scalable font), the print direction can rotation Angle for 0 °, 90 °, 180 °, 270 °
Barcode 1 - D bar code:
Code 39, the Code 93, Code 93 (subset of A, B, C), UCC/EAN - 128 - K Mart, UCC/EAN - 128, UPC A/E (add on 2 & 5), the I 2 of 5, the I 2 of 5 with Shipping Bearer Bars, EAN 8/13 (add on 2 & 5), Codabar, Post NET, EAN 128, DUN 14, HIBC, MSI Mod 10 (1), the Random Weight, Telepen, FIM, China Postal Code, RPS 128 and GS1 DataBar
2 - D codes:
PDF417, Datamatrix code, MaxiCode, QR code and Micro QR code
CODEPAGE 437, 850, 851, 852, 855, 857, 861, 862, 863, 865, 866, 869, 869, 869, 737
WINDOWS 1250, 1251, 1252, 1253, 1254, 1255
Unicode (UTF8, UTF16)
Graphics processing support monochrome PCX, BMP, and other diagram file types can be supported by software control
Communication interface USB: V2.0 (set to start)
Control panel a three-colour LED indicator: red, orange, green
A set of multifunctional hardware control keys: feeds
Power supply Auto: 100-240vac, 50-60hz (dc automatic Switching power supply)
Working environment temperature operation: 41 ° F to 104 ° F (5 ° C to 40 ° C)
Storage temperature: - 4 ° F to 122 ° F (20 ° C to 50 ° C) -
Humidity: 30-85%, air flow, no condensation
Humidity: 10-90%, air circulation, no condensation
(EMC), FCC Class A, CB, CCC
Body size: 254 mm (10 ")
Height: 170 mm (6.7 ")
Width: 224 mm (8.8 ")
Body weight < 2.5 kg (5.5 LBS)
Select the Internal rs-232 card
Ethernet 10/100mbps print server (default off; disables USB when in use)
External label roll holder for 10 "(250 mm) O.D. label rolls
External label rewinder
Note that the trademarks mentioned above are all owned by the original company
