models
economical
TTP - 246 - m Pro
TTP - 344 - m Pro
Print resolution
203 DPI
300 DPI
Print type
Heat transfer/heat inductance
The printing speed
Up to 8 ips
The highest 6 ips
Maximum print width
108 mm (4.25 ")
104 mm (4.09 ")
Maximum print length
2286 mm (90)"
1016 mm (40)"
structure
Chassis and main body: alloy casting; Metal shell; Transparent window design
size
505 mm (D) * 270 mm (W) * 308 mm (H)
The weight of the
15 KG
The size of the paper roll
208.3 mm (8.2 ") outer diameter
Carbon belt loading
1 "inner diameter, maximum capacity of 600 m carbon belt (inner volume and external volume are applicable)
Carbon belt width
25.4 mm - 114.3 mm (1 "-4.5")
Central processing unit (CPU)
32 - bit RISC CPU
memory
4 MB FLASH, 8 MB SDRAM
Operation panel
LCD LCD display (128 * 64 pixels), 3 LED lights, 6 sets of buttons
The sensor
Through the sensor, the reflector, the carbon strip ends the sensor, and the print head lifts the sensor
RTC
standard
Transmission interface
Rs-232c (2400-115200 BPS), and USB 2.0
Built-in fonts
Eight kinds of lattice the digital type, 8 kinds of fonts (8 * 20 dec 12, 12 * * 32 * 24, 24, 32 * 48, 14 * 19 (OCR - B), 21 * 27 (OCR) - B, 14 x 25 (OCR - A), MONOTYPE vector fonts engine and CG Triumvirate Bold Condensed Scalable Font vector fonts and downloadable Windows fonts to use
A dimensional barcode
Code 39, Code 39C, Code 128UCC, Code 128 subsets A.B.C., Code 11, Codebar, interleaved 2 of 5, EAN -13, EAN -128, upc-a, puc-e, EAN and UPC 2 (5) dights add - on, CHINA POST, MSI, PLESSEY, POSTNET
Two dimensional barcode
PDF - 417, Maxicode, DataMatrix, QR code
Programming language
TSPL - EZ
Safety certification
FCC Class A, CE Class A, c-tick Class A, UL, CUL, TUV/GS, CCC, CB
Environmental conditions
Operating temperature 5-40 C, storage temperature: -5-60 C
Editing software
BarTender Labeling Software
Customer optional
Stand-alone keyboard (Plus/KU KU - 200-200), an external type wireless network module, contact mask barcode scanners, long-distance linear image barcode scanners, guillotine cutter, spiral cutter knife type of thick paper
Dealer selection
Multi-function interface modules: module 1: contains internal Ethernet server, PS / 2 keyboard connection interface, SD card memory expansion slot module 2: includes automatic labeling machine connection interface, internal Ethernet server, PS / 2 keyboard connection interface, SD card memory expansion slot
